Patient Monitor

Main Features:

• 12.1" Color TFT LCD display with waveforms upto 8 Channels.
• Portable, streamline handle design.
• Monitor measures from Adult and Neonates.
• Graphic and tabular trend for 96 hours for all parameters.
• Multi-Screen format.
• Audible and Visual Alarms with adjustable alarm ranges.
• Powerful data management and storage capacity.
• Manual or Automatic NIBP measuring.
• With 500unit memory.
• Rechargeable Battery Backup.
• Weight : 4.5 Kg. approx.


Respiration:

• Method : RA-LL impedance
• Measurement Range : Adult : 0-120rpm, Paediatric Neonatal : 0-150rpm
• Apnea Alarm : Yes


Temperature:

• Resolution : 0.1° C
• Channels : Dual - Channel
• Measurement Range : 0-50° C


IBP (Ungradable):

• Channel : 2 Channels
• Pressure Transducer : Sensitivity : 5 (mV V mmHg)
• Transducer Site : ART, PA, CVP, RAP, LAP, ICP
• Alarm Range : -10~300mmHg


ECG:

• 5-lead or 12-lead selectable
• Input : 5-lead : RA; LA; RL; LL; V Or R; L; F; C
• Lead Selection : I; II; III; avR; avL; avF; Vx; CAL
• Gain Selection : x0.25, x0.5, x1, x2, auto
• Sweep Speed : 12.5mm/s, 25mm/s, 50mm/s
• Accuracy : +1bpm or +1%, whichever is greater
• Protection : Withstand 4000V AC/50Hz Voltage in isolation against electrosurgical and defibrillation
• Calibration Signal : 1mV=5%
• Operation Modes : Diagnostic, Monitor, Surgery
• Heart Rate Range : Adult : 15-300bpm Paediatric / Neonatal : 15-350bpm
• Measurement Range : -2.0mV ~ 2.0mV
• S-T Detection : Yes, Audible and Visual Alarm, Alarm events recallable


NIBP:

• Method : Oscillometry
• Operation Modes : Manual Automatics / STAT
• Measurement Unit : mmHg / KPa selectable
• Measurement types : Systolic, Diastolic, Mean
• Measurement Range : Adult : 10-270mmHg
• Over-Pressure Protection : Yes
• Resolution : 1mmHg
• Accuracy : The mean error shall be less than ±5mmHg, the standard deviation shall be less than ±8mmHg
• Alarm : Systolic, Diastolic, Mean


SPO2:

• Measurement Range : 0-100%
• Accuracy :±2% (70~100%); 0~69% Unspecified
• Alarm Range : 0-100%

Main Features:

• 12.1'' TFT color LCD, 15-language interface(Simplified Chinese, Traditional Chinese, English, French, German, Turkish, Spanish, Portuguese, Italian, Dutch, Romanian, Russian, Kazakhstan, Polish, Czech).
• Fanless design, quiet, energy-saving and clean, which reduces the possibility of cross-infection.
• All-round monitor for adult, pediatric and neonate.
• With standard interface, OxyCRG, trend chard, big character interface and view bed, convenient to observe.
• Waveform, parameter color and location can be set optionally.
• Operation mode: keys and buttons.
• Display up to 8-channel waveform on one screen.
• Display 7-lead ECG waveform on one screen, and with ECG step function.
• Adopt digital SpO2 technology, anti-motion and anti-ambient light interference, and measurement can be performed under the circumstance of weak filling.
• HRV analysis function.
• NIBP measurement mode: Manual/AUTO/Continuous, storage for 4800-group NIBP data.
• Review for 71 alarm events of all parameters and 60 arrhythmia alarm events.
• Drug concentration calculation and titration table functions.
• Print trend table data with one-key.
• Connect to Central Monitoring System by 3G, WiFi or wired mode.
• AC/DC, built-in rechargeable lithium battery achieve uninterrupted monitoring.
• Anti-high frequency surgical unit, defibrillation-proof(special leads are necessary).

Main Features:

• 8" TFT color LCD, multi-language interface (Simplified Chinese, Traditional. Chinese, Engligh, French, German, Turkish, Spanish, Portuguese, Italian, Dutch, Romanian, Russian, Kazakhstan, Polish, Czech).
• Fanless design, quiet, energy - saving and clean, which reduces the possibility of cross-infection.
• All-round monitor for adult, pediatric and neonate.
• With standard interface, OxyCRG, trend chard, big character interface and view bed, convenient to observe.
• Waveform, parameter color and location can be set optionally.
• Operation mode : Keys and buttons.
• Display upto 8-Channels waveform on one screen.
• Display 7 lead ECG waveform on one screen and with ECG step function.
• Adopt digital SpO2 technology, anti-motion and anti-ambient light interference and measurement can be performed under the circumstance of weak filling.
• HRV analysis function.
• NIBP measurement mode : Manual/AUTO/STAT, storage for 4800-group NIBP dada.
• Review for 71 alarm events for all parameters and 60 arrhythmia alarm events.
• Drugs concentration calculation and titration table functions.
• Print trend table data with one key.
• Connect to central monitoring system by 3G, WiFi or Wired mode.
• AC/DC, built-in rechargeable lithium battery achieve uninterrupted monitoring.
• Anti-high frequency surgical unit, defibrillation-proof (Special leads are necessary)

This model can monitor such parameters as ECG, RESP, NIBP, SpO2, PR, Dual- channel TEMP, dual-channel IBP and EtCO2. It integrates parameter measurement module, display and recorder in one device to form a compact and portable equipment. At the same time, its built-in replaceable battery provides convenience for patient moving. This equipment adopts full-isolation(floating), ECG defibrillation-proof protection, ECG anti-high frequency interference and NIBP dual-protection for over-pressure, to ensure monitoring quality and reduce operation risk, which is applicable for monitoring adult, pediatric and neonate.

Main Features:

• Elegant appearance, clear marks, standard interface, oxygen graph, trend graph, big characters, other BED observation, which are convenient for users.
• Standard parameters: ECG, RESP, NIBP, SpO2 and dual-channel TEMP. IBP, CO2 and built-in printer are optional.
• Fifteen languages are optional, and all operations can be finished by keys and buttons.
• 15'' color LCD displays patient parameter and waveform collected, and alarm, bed NO., clock, equipment state and other information provided by the monitor synchronously.
• Monitoring parameters, scan speed, volume and output contents can be set optionally.
• Storage of 480-hour trend data, and review of 34-second holographic waveform.
• Adopt digital SpO2 technology, strong in anti-interference and anti-weak filling capability.
• Calculation of drug concentration.
• Built-in rechargeable battery for uninterrupted monitoring.
• Print ECG, SpO2, RESP, BP and TEMP data with one-key.
• Anti-high frequency surgical unit, defibrillation-proof(requirement for special leads).
• Optional functions: Moving bracket, hanging bracket, VGA output and 12-lead.

This multi-parameter patient monitor is our newest product. The display is 8 inch high resolution color TFT.

Main Features:

• 8" high resolution color screen.
• Exquisite design suitable to moving operation.
• Operation interface: Standard, Trend Screen, oxyCRG Screen, NIBP List, Big font Screen.
• Freeze instant waveform for real time S-T segment analysis, pace-maker detection.
• Storage for up to 400 groups of NIBP list, 60 alarm events record recall.
• Built-in rechargeable lithium battery with 4 hours working capacity.
• Capture dynamic wave forms.
• Patient info input management function.


Standard Configuration :

• SpO2, PR, NIBP, ECG, RESP, TEMP

Option Configuration :

• ETCO 2

This multi-parameter patient monitor is a robust patient monitor, small enough to move around, yet flexible enough to adapt to your particular needs. With a variety of optional extras, including arrhythmia and ST analysis, EtCO2 measurement and double IBP, AQUA 12 multi-parameter patient monitor is configurable to suit your requirements. Purchase only the advanced features that you need and nothing more. With NIBP recall and extensive data storage capability , AQUA 12 multi-parameter patient monitor is particularly well-suited for use in peri-anesthesia and critical care environments. Rich in functions, conveniently adaptable and pleasingly affordable, AQUA 12 multi-parameter patient monitor may be just the monitor for your department.

Main Features:

• 12.1" high resolution color TFT LCD Screen.
• Thinner and lighter design, convenient and portable for user.
• Freeze instant waveform for real time S-T segment analysis, pace-maker detection.
• Full touch screen selectable, more convenient for operation.
• Real time S-T segment analysis, pace-maker detection.
• 3-level audio/visual alarming.
• Efficient resistance to interference of defibrillator and HF knife.
• Lasting working capacity with built-in rechargeable lithium battery.
• 400 groups of NIBP list, 6000 seconds ECG waveform recall. 60 alarm events record recall, 7-day trend chart in storage.
• Wire/wireless central monitoring system applicable to ICU/CCU/OR

Standard Configuration :

• SPO2, PR/HR, NIBP, ECG, RESP, 2-TEMP.

Option Configuration :

• ETCO2, 2-IBP, Nellcor SpO2, Thermal Printer, Touch Screen.
