Slim LED X-Ray View Box – 25 mm Profile with Dimmer & Automatic Film Sensor
The IndoSurgicals Slim LED X-Ray View Box is a professional X-ray film viewer and LED film illuminator designed for clear viewing of conventional radiographic films in hospitals, radiology departments, diagnostic centres, clinics and medical institutions. Its 25 mm ultra-slim profile, approximately 10,000 Lux illumination, adjustable brightness and automatic film-activation sensor combine efficient film viewing with a compact, modern design.
Slim LED X-Ray Film Viewer for Radiology & Medical Imaging
Conventional radiographic films require controlled, evenly distributed backlighting for practical visual review. The IndoSurgicals Slim LED X-Ray View Box uses an edge-lit LED illumination system to spread light across the viewing panel and provide a bright, substantially uniform viewing surface for radiographic films.
The cabinet is only 25 mm thick, making it considerably slimmer than traditional fluorescent or deeper box-type X-ray film illuminators. This compact profile is useful in radiology rooms, consultation areas, operating environments, teaching facilities and other locations where wall or work-surface space is limited.
A built-in brightness dimmer allows the user to adjust screen luminance according to the film and ambient viewing conditions. Each film bank is also equipped with its own automatic activation sensor, so multi-film configurations provide separate control for the corresponding viewing sections.
The slim 25 mm range is available in Single, Double, Triple and Four Film configurations. Select capacity from the films normally reviewed together, installation space and the facility's workflow.
Edge-Lit LED Technology
LEDs positioned around the panel edges distribute illumination through the viewing surface for bright and consistent film viewing.
25 mm Slim Profile
All four configurations use an ultra-slim 25 mm cabinet depth for space-efficient installation.
Adjustable Brightness
Integrated dimmer control allows luminance to be adjusted for different film densities and viewing conditions.
Automatic Film Sensor
Film activation sensor provides convenient illumination control when radiographic film is positioned for viewing.
Approx. 10,000 Lux
High-brightness LED illumination supports clear visualisation of conventional X-ray films.
Approx. 100,000-Hour LED Life
Long-life LED light source reduces the frequency of lamp replacement compared with conventional lighting systems.
Bright, Uniform Light for Radiographic Film Viewing
The viewing panel uses an edge-lit LED arrangement to distribute light across the illuminated area. The current specification lists approximately 10,000 Lux brightness, 8000 K color temperature and more than 95% luminance uniformity.
Brightness
High-output illuminated surface for reviewing conventional radiographic films.
Color Temperature
Stated color-temperature specification across all four viewing configurations.
Luminance Uniformity
Designed to minimise significant bright and dark variation across the viewing panel.
Approx. LED Life
Long-life LED light source according to the current product specification.
Independent Brightness Control and Film Activation for Each Bank
Each illuminated film bank is equipped with a brightness adjustment control and an automatic film sensor. This arrangement becomes particularly useful on the Double, Triple and Four Film versions, where separate banks can be operated according to the films being reviewed.
Brightness Dimmer
The dimmer allows the user to increase or decrease viewing brightness according to film density, ambient light and personal viewing preference.
Automatic Film Sensor
Each film bank has a corresponding activation sensor, supporting convenient control when a film is positioned in the viewing section.
Secure Clamping Arrangement for Radiographic Films
The Slim LED X-Ray View Box uses a clamping-type film holding arrangement designed to secure radiographic films of different thicknesses during viewing.
Secure Film Retention
Clamping mechanism helps keep the film in its selected viewing position.
Different Film Thicknesses
Designed to accommodate conventional radiographic films with varying material thickness.
Easy Placement
Practical retaining arrangement supports repeated placement and removal during routine film review.
Single, Double, Triple and Four Film X-Ray View Boxes
The Slim LED series is available in four widths while retaining the same 17-inch viewing height and 25 mm cabinet depth. Select the configuration according to the number of films that need to be viewed side by side.
Single Film · 14 × 17 in viewing area 2 FILM
Double Film · 28 × 17 in viewing area 3 FILM
Triple Film · 42 × 17 in viewing area 4 FILM
Four Film · 56 × 17 in viewing area
| Specification | Single Film | Double Film | Triple Film | Four Film |
|---|---|---|---|---|
| Viewing Area | 14 × 17 inches | 28 × 17 inches | 42 × 17 inches | 56 × 17 inches |
| External Size | 505 × 504 × 25 mm | 884 × 504 × 25 mm | 1257 × 504 × 25 mm | 1635 × 504 × 25 mm |
| Brightness | 10,000 Lux | 10,000 Lux | 10,000 Lux | 10,000 Lux |
| Color Temperature | 8000 K | 8000 K | 8000 K | 8000 K |
| Input | AC 100–270 V, 47–53 Hz | AC 100–220 V, 50 Hz | AC 100–220 V, 50 Hz | AC 100–220 V, 50 Hz |
| Power | 30 W | 60 W | 90 W | 120 W |
Suitable for Wall Mounting or Desk Installation
The slim 25 mm enclosure supports efficient use of available space and can be integrated into different clinical environments. The current product specification provides for both wall-mounted and desk-mounted use.
Wall Mounting
The shallow 25 mm profile is well suited to fixed wall installation in radiology rooms, consultation areas, reporting spaces and clinical departments.
Desk / Work-Surface Use
The viewer can also be used in a desk-based installation where portability of placement or work-surface access is preferred.
Applications of Slim LED X-Ray Film Viewers
The Slim LED X-Ray View Box is designed for facilities that continue to review conventional radiographic films and require a bright, controllable illuminated viewing surface.
Radiology Departments
For routine viewing and discussion of conventional X-ray films in hospital radiology environments.
Diagnostic Centres
Suitable for centres requiring dedicated radiographic film viewing equipment.
Hospitals & Clinics
Can be installed in consultation rooms, departments and treatment areas where films need to be reviewed.
Orthopaedic Clinics
Useful for reviewing conventional musculoskeletal and orthopaedic radiographs.
Medical Colleges
Suitable for teaching environments where radiographic films are demonstrated to students.
Dental & Medical Imaging
Can be used wherever compatible conventional radiographic film needs illuminated visual review.
Slim LED X-Ray View Box Specifications
| Specification | Single Film | Double Film | Triple Film | Four Film |
|---|---|---|---|---|
| Viewing Area | 14 × 17 in | 28 × 17 in | 42 × 17 in | 56 × 17 in |
| External Dimensions | 505 × 504 × 25 mm | 884 × 504 × 25 mm | 1257 × 504 × 25 mm | 1635 × 504 × 25 mm |
| Cabinet Depth | 25 mm | 25 mm | 25 mm | 25 mm |
| Light Source | LED | LED | LED | LED |
| Illumination | 10,000 Lux | 10,000 Lux | 10,000 Lux | 10,000 Lux |
| Color Temperature | 8000 K | 8000 K | 8000 K | 8000 K |
| Luminance Uniformity | >95% | >95% | >95% | >95% |
| Approx. LED Life | 100,000 h | 100,000 h | 100,000 h | 100,000 h |
| Brightness Control | Dimmer | Separate dimmer per bank | Separate dimmer per bank | Separate dimmer per bank |
| Film Sensor | 1 sensor | 2 sensors | 3 sensors | 4 sensors |
| Electrical Input | AC 100–270 V, 47–53 Hz | AC 100–220 V, 50 Hz | AC 100–220 V, 50 Hz | AC 100–220 V, 50 Hz |
| Rated Power | 30 W | 60 W | 90 W | 120 W |
| Mounting | Wall / Desk | Wall / Desk | Wall / Desk | Wall / Desk |
Which X-Ray View Box Size Should You Choose?
Single Film
Compact 14 × 17 inch viewing area for locations where one standard radiographic film is normally reviewed at a time.
Double Film
28 × 17 inch viewing area for comparing two films side by side.
Triple Film
42 × 17 inch viewing surface for departments requiring simultaneous display of up to three film banks.
Four Film
Large 56 × 17 inch viewing area for high-capacity film comparison and multi-film review.
Wall Space
Confirm available wall width before selecting Double, Triple or Four Film configurations.
Workflow Requirement
Choose the number of banks according to how many radiographic films are routinely compared at one time.
Maintain the Viewing Surface and Electrical Components Carefully
Keep the Panel Clean
Remove dust, fingerprints and marks using cleaning methods appropriate for the viewing surface.
Protect from Impact
Avoid striking, bending or placing heavy loads against the illuminated panel and slim enclosure.
Use Correct Power Supply
Confirm the electrical input specification of the selected film-bank configuration before installation.
Product Selection and Quotation Support
IndoSurgicals Private Limited manufactures and supplies medical X-ray accessories and film-viewing equipment for hospitals, diagnostic centres, radiology departments, clinics, medical colleges, healthcare institutions, dealers, distributors, project buyers and international customers.
For a current quotation, share the required film configuration, quantity, delivery destination and any installation, documentation or tender requirements.
Request a Quote for Slim LED X-Ray View Boxes
Select Single, Double, Triple or Four Film configuration and share your required quantity, destination and procurement requirements for current pricing and quotation.
